CNC Fiber Laser with Plasma & Oxyfuel Cutting Machine
(3-in-One Machine)
Product Discription
The CNC Fiber Laser with Plasma & Oxyfuel Cutting Machine from TECHPRO CNC SOLUTIONS is a versatile, multi-process cutting system designed to handle a wide range of metal cutting applications. By combining fiber laser, plasma, and oxyfuel technologies in a single machine, it provides unmatched flexibility, precision, and efficiency. This system is ideal for industries that require high-speed cutting of thin materials with laser, high-performance plasma cutting, and thick plate cutting with oxyfuel.
Take your metal cutting capabilities to the next level with the CNC Fiber Laser with Plasma & Oxyfuel Cutting Machine
– a true game-changer in precision cutting technology!
Product Details
Specifications
- Laser Power Sources: MAX / RAYCUS / IPG
- Plasma Power Sources: HYPERTHERM
- Auto-Focus Cutting Head: Raytools / Bochu
- Cutting Accuracy: ± 0.5mm
- Structure: Heavy Duty Gantry Type
- Maximum Rapid Speed: 12,000 mm/Min
Machine Sizes (Working Area)
- Working: 2100 x 6500 mm (TP-2065 LPO)
- Working: 2500 x 6500 mm (TP-2565 LPO)
- Standard: 3100 x 6500 mm (TP-3065 LPO)
- Working: 3100 x 8500 mm (TP-3085 LPO)
- Working: 3100 x 12500 mm (TP-3012 LPO)
- As per requirements
Cutting Thickness
- Depends on Power-Sources
- Laser: 0.5 to 25mm (Mild Steel)
- Laser: 0.5 to 20mm (Stainless Steel)
- Plasma: 0.5 to 32mm (Mild Steel)
- Plasma: 0.5 to 25mm (Stainless Steel)
- Oxyfuel: 6mm to 250mm (Mild Steel Only)
Fiber Laser Power Sources
- MAX / RAYCUS / IPG : 1500 W (1.5 KW)
- MAX / RAYCUS / IPG : 2000 W (2 KW)
- MAX / RAYCUS / IPG : 3000 W (3 KW)
- MAX / RAYCUS / IPG : 6000 W (6 KW)
- MAX / RAYCUS / IPG : 12000 W (12 KW)
- MAX / RAYCUS / IPG : 20000W (20 KW)
Plasma Power Sources
- Hypertherm Powermax 45 XP
- Hypertherm Powermax 65 A
- Hypertherm Powermax 85 A
- Hypertherm Powermax 105 A
- Hypertherm Powermax 125 A
- Hypertherm Maxpro 200 A
Key Features:
- ✅ Multi-Process Cutting Capability: Fiber Laser for precision cutting, Plasma for high-speed metal cutting, and Oxyfuel for thick plate cutting.
- ✅ Gantry-Type Heavy-Duty Structure: Heavy Duty Gantry Type Structure Ensures high stability, durability, and smooth cutting operation.
- ✅ Easy Upgrade & Integration: easy to upgrade or integrate with Higher cutting Thickness Sources as your production needs grow.
- ✅ Advanced CNC Control System: User-friendly interface with customizable cutting parameters and automatic nesting software.
- ✅ High-Speed Fiber Laser Source: Delivers clean, precise cuts with minimal heat-affected zones.
- ✅ High-Definition Plasma Cutting: Ideal for cutting stainless steel, aluminum, and mild steel with high speed and accuracy.
- ✅ Oxyfuel Cutting Torch: Enables cost-effective cutting of thick carbon steel plates with smooth edges.
- ✅ Automatic Torch Height Control (ATHC): Maintains optimal cutting height for laser, plasma, and oxyfuel processes.
- ✅ Customizable Worktable Size: Designed to accommodate various plate sizes and material thickness requirements.
- ✅ Low Maintenance & High Reliability: Engineered for long-term performance with minimal downtime.
